Fly Ash Brick Making Machine (RBM-40)

Doing justice to the stellar reputation of ours, we offer our admired customers an assorted range of Fly Ash Brick Making Machine (RBM-40). We are committed towards meeting our customers’ exact requirements. We procure raw materials from the vendors who can deliver absolute quality on a consistent basis. The efficient working and user friendly design of this product on offer puts it in the instant hit bracket among the customers.

Details :

• Heavy structure body with four nos. of shaft to guide the Ram Punch of Mould, Electric Panel (With Mitsubishi PLC,) Limit Switch/Proximity Sensors, Hopper,  Cylinder Made by Honed Tube. Piston Is Hard Chrome.
• Production Capacity  40,000 to 45,000 Bricks/Shift. 7.5x2 H.P. Mould Vibrator, [Automatic material feeder and Pallet Feeder, Hydraulic operated, controlled by PLC
• Hydraulic Power pack of  400 Ltr. Capacity,  with Flange type motor, Douty Gear Pump, Yuken Valves, Oil filters at Incoming , outgoing and return line. Electric Motor 20HP 3PH of Crompton / Havells, Complete With Power Pack , Water cooler arrangement.
• Pan Mixer - 2 No. “Reva” Pan Mixer having capacity of 750 Kgs. fitted with 2 Nos. heavy C.I.Rollers, fitted with changeable bottom wear plates fitted with mixing and discharge  blades, having special alloy steel tips, complete with quality Worm Reduction Gear Box Elecon/Radicon make powered by 25 H.P./Electric Motor of Kirloskar/Crompton/Havells make With Star-Delta starter.
• Belt Conveyor - 1 No. “Reva” Belt Conveyor for loading and unloading the material of the Pan Mixer of app. 30 ft.and powered by 3 H.P.Electric Motor of Havells / ABB/ Siemens/Bharat Bijlee  make fitted with quality gear box with starter. The conveyor is fitted with rubber top nylon conveyor belt and is moving on frictionless idlers
• Mould - (32 Cavity). 32 Bricks/Stroke  with Frog (Name in Brick).
• Pallet Trucks

  • 4 Nos. “Reva” Pallet Trucks are fitted with hydraulic lifting, hand pumping and manual dragging arrangement with lift capacity of 1000 Kgs.
  • Automatic Material Feeder, Hydraulic Operated
  • Automatic Pallet Feeder, Hydraulic Operated
  • Finished Fly-Ash Bricks Pallet Conveyor , powered by 01 H.P. Geared Motor.
• Auto Batching System of  2+1 Bins for Raw  Material. Weighing of the Raw Material on the Belt Conveyor with help of the Load Cells and Automatic Batch controlSystem and Computer Printing Facility and one week data storage.
• Automatic Discharge of the Raw Material. Weighing conveyor controlled by 7.5 H.P. Geared Motor and ½ H.P. Chute vibrator on the Bins of Aggregate.
• Automatic Stacker - Automatic Stacker for Lifting the Pallets with Bricks. Powered by 01+03 H.P. Electric Motor, Controlled by Variable Frequency Drive.
